Showven uFlamer X5

The uFlamer X5 is a hydraulic flame head with five outputs, and each nozzle can be fired on its own. It is part of Showven's flame system for truss and permanent installs, fed by a pump station. There is no nitrogen tank to manage, and it mounts in any direction. Flames run from 3 to 10 m in still air, it works in rain, and it has triple ignition and a mechanical pressure gauge. We supply it new, tested in our warehouse before it ships, and our SFX team can help you design the system around it.
Specifications

Dimensions: 435 × 380 × 405 mm
Weight: 40 kg
Housing material: 304 stainless steel
Input: AC 100–240 V, 50/60 Hz
Work power: 400 W
Flame height: 3–10 m (no wind)
Usage in rain: Yes
Ignition: Triple high-voltage electronic ignition
Control: DMX, 9–60 V pyro signal
Quick couplers: ISO7241B G1/4 male
Work pressure range: 8–12 bar
Firing angles: 5
Installation direction: Any direction
Fuel: ISOPAR L
Pressure gauge: Yes, mechanical
