Showven DMX Splitter 8

The DMX Splitter 8 takes one DMX signal, buffers and boosts it, and splits it into eight separate outputs. Used with the FXcommander and Showven effects, it passes data both ways. Every input and output is electrically isolated, rated above 1000 V input to output and output to output. It has a 304 stainless steel housing and Neutrik connectors throughout. We supply it new and test it in our warehouse before it ships, and our SFX crew can help you plan your DMX runs.
Specifications

Model: DMX Splitter 8
Dimensions: 530 × 153 × 49 mm
Weight: 2.8 kg
Input: AC 220 V / 110 V, 50/60 Hz
Work power: 5 W
Housing material: 304 stainless steel
Interface: Neutrik PowerCON TRUE1; Neutrik DMX in × 1; Neutrik DMX thru × 1; Neutrik DMX out × 8
